Switch Specifications
Rating:3A 250VAC 2A 36VDC
Degree of protction:1P65;
Contact Resistance:50mQ Max.
Dielectric Strength:1000VAC For 1 minute
Total Travel: 3.0+0.5mm
Operating Force:450+150gf;
Mechanical Life:200,000cycles
Load Life:50,000 cycles
Operating Temperation:-20°C~70°C
Function:Momentary

  • Icconntec

Availability:
Quantity:
Inquire Add to Basket

Switch Specifications

Rating:3A 250VAC 2A 36VDC
Degree of protction:1P65;

Contact Resistance:50mQ Max.


Dielectric Strength:1000VAC  For 1 minute
Total Travel: 3.0+0.5mm
Operating Force:450+150gf;
Mechanical Life:200,000cycles
Load Life:50,000 cycles
Operating Temperation:-20°C~70°C
Function:Momentary


Push Button Switch
